Automatic Tapping Machine

Automatic Tapping Machine Specification

Product Type
Automatic Tapping Machine

General Use
Industrial threading, tap cutting of various metal parts

Material
Cast Iron Body, Hardened Steel Components

Type
Automatic, Column Type

Capacity
Up to M16 (Steel), M20 (Aluminium)

Weight (kg)
Approx. 350-500 kg

Computerized
No

Automatic
Yes

PLC Control
Available/Optional

Bar Feeder
Optional (External Accessories)

Power Source
Electric

Power Consumption
1.5 kW - 2.2 kW (Approx.)

Rigidity
High rigidity cast iron structure

Voltage
220V/380V, 50Hz/60Hz

Motor
Powerful Single/Three Phase Motor

Table Size
Approx. 350 x 250 mm

Spindle Speed
702000 RPM (Variable Speed)

Axial Choice
Vertical

Dimension (L*W*H)
Approx. 700 x 650 x 1500 mm

Feature
Automatic operation, Precision tapping, Adjustable depth control

Color
Blue and Silver

Clamping Range
2 mm16 mm

Control Panel
Digital with Overload Protection

Tapping Accuracy
0.02 mm

Lubrication System
Centralized Automatic Lubrication

Coolant System
Integrated Coolant Recirculation

Chuck Type
Quick Change Tapping Chuck

Noise Level
< 75 dB

Application Range
Suitable for ferrous and non-ferrous metals

Safety Equipment
Emergency Stop, Overload Relay

Tapping Stroke
Max. 100 mm

About Automatic Tapping Machine

Adjustable settings allow for optimization based on material, tap size, and thread type.
Automated Reverse Function: Safely retracts the tap after threading.
Precision and Consistency: Automated systems ensure accurate and consistent thread formation, reducing human error.
Integration: Can be integrated into production lines for streamlined manufacturing.
Ensures consistent and accurate thread formation, leading to higher quality products.
Cost-Effectiveness: By reducing labor costs and material waste, these machines can lead to overall cost savings.
Enhanced Safety: Reduces the risk of injury associated with manual tapping.

Applications:

Manufacturing: In various manufacturing processes, creating threads in components like bolts, nuts, and other parts.
Automotive Industry: Used in the production of various automotive components.
Other Industries: Also used in aerospace, plumbing, and construction, wherever threaded holes are needed

Precision Tapping Performance

Achieve exceptional accuracy with a tapping precision of 0.02 mm and rapid setup using the quick change tapping chuck. The machine is suitable for tapping various ferrous and non-ferrous metals, ensuring quality results even for demanding industrial applications. Variable spindle speed and automatic depth control let you match settings to specific job requirements for optimal performance.

User-Friendly Operation and Safety

The automatic tapping process is managed via a digital control panel, featuring overload protection that safeguards the machine and operator. Emergency stop and overload relay further enhance workplace safety. Integrated coolant recirculation and centralized lubrication ensure smooth operation, while a noise level below 75 dB maintains a comfortable work environment.

Built for Industrial Longevity

Constructed from high-rigidity cast iron with hardened steel components, this tapping machine is built to endure rigorous use. Adjustable clamping, optional bar feeder, and availability of PLC control provide flexibility for diverse applications. Maintenance is simplified with an automatic lubrication system, promoting reliable long-term performance in any industrial setting.

FAQ's of Automatic Tapping Machine:

Q: How does the automatic tapping machine maintain high precision during operation?

A: The machine achieves consistent precision (0.02 mm) by combining a rigid cast iron body, quick change tapping chuck, and a digital control panel. Centralized lubrication and integrated coolant recirculation system further support repeatable accuracy throughout extended use.

Q: What materials and thread sizes can this machine handle?

A: This automatic tapping machine is suitable for both ferrous and non-ferrous metals. It accommodates a clamping range of 2 mm-16 mm and can tap threads up to M16 in steel and M20 in aluminium, making it versatile for various industrial applications.

Q: When is overload protection activated during tapping operations?

A: Overload protection is triggered automatically when the machine detects excessive load on the spindle, preventing mechanical or motor damage. This ensures reliable performance while safeguarding the equipment and operator.

Q: Where can this machine be installed within a facility?

A: With dimensions of approximately 700 x 650 x 1500 mm and minimal noise emission (<75 dB), this tapping machine is suitable for most industrial shop floors, threading workstations, or dedicated assembly lines.

Q: What is the process for changing taps using this machine?

A: Thanks to the quick change tapping chuck, changing taps is straightforward and rapid, requiring minimal downtime. Simply disengage the current tap and insert the new one within seconds, streamlining production workflows.

Q: How is the lubrication and cooling managed on the tapping machine?

A: The machine is equipped with a centralized automatic lubrication system and an integrated coolant recirculation system. These features ensure continuous and optimal lubrication and cooling throughout operation, extending the life of machine components.

Q: What are the main benefits of using this automatic tapping machine?

A: Primary benefits include precision threading, high durability, reduced operator fatigue due to automation, enhanced safety features, and ease of operation. Optional accessories and configurable controls further extend its adaptable use across multiple metalworking applications.
