ART 200 CNC Chucker Machine

ART 200 CNC Chucker Machine

1075000 INR/Piece

Product Details:

  • Product Type CNC Chucker Machine
  • General Use Industrial use
  • Material Metal
  • Type Horizontal Turning Center
  • Weight (kg) 2500 Kilograms (kg)
  • Computerized Yes
  • Automatic Yes
  • Click to View more
X

ART 200 CNC Chucker Machine Price And Quantity

  • 950000.00 - 2000000.00 INR/Piece
  • 1075000 INR/Piece
  • 1 Piece

ART 200 CNC Chucker Machine Product Specifications

  • 7kw Kilowatt (kW)
  • Yes
  • Yes
  • White
  • High
  • Yes
  • Metal
  • 2500 Kilograms (kg)
  • Industrial use
  • Yes
  • 3500 mm/m
  • CNC Chucker Machine
  • Horizontal Turning Center
  • Electric
  • 240-480 Volt (v)
  • 1.5 x 2 Meter (m)
  • AC Motor

ART 200 CNC Chucker Machine Trade Information

  • 30 Piece Per Month
  • 1 Minutes
  • shrink packing
  • Haryana Uttar Pradesh Delhi

Product Description

ART 300 CNC Chucker Machine that proposed by is engineered to be utilized for hardware as well as automotive components & parts. This type of machine is ideal suitable for various components starter motor cover, pins, LPG valves, plunger, bearing races, ball, bushes, sleeves, gears, tractor, and so on. The machine is equipped with technologically advanced control system, which enable operators to run all operations smoothly. The ART 300 CNC Chucker Machine is easy to operate, cost-effective, performance and requires less maintenance.

Payment Terms  :

    cheque
    Rtgs
    Bank transfer
    Online

We mainly deal in local area

Specifications:

DETAILS

UNITS

SPECIFICATIONS

Bed type/ guide way type



Slant / linear

Max. Swing diam. Over bed

Mm

 400

Max. Swing diam. Over slide

Mm

 120

Max length of work piece

Mm

100

Spindle bore

Mm

40

Spindle Type



A25 Cartridge, Belt driven

Spindle Speed

Rpm

100-3500

Chuck Size

Mm / no.

165 / 3 jaws

Main motor power

KW

5.5/ 7.5

X/Z travel

Mm

320/160

X/Z rapid traverse

mm/min

20/20

Type of tool changer



Linear Tooling

No. of tool station



1-4 ( depending upon the job size)

Tool shank size

Mm

25 x 25

Coolant pump motor power

W

90

Clamping



Hydraulic Chuck



Positioning accuracy X/Z

Mm

0.007/0.007

Repeatability X/Z

Mm

0.005/0.005

Dimensions

Mm

1900x 1350x 1750

Net weight (approx.)

Kg

2500

CONTROL SYSTEM

Siemens 808D Advanced
